Keepalived VRRP Configuration: Master/Backup on Linux

High availability on bare‑metal or virtual servers doesn’t have to be complex. In this guide you’ll configure Keepalived with VRRP to provide a floating Virtual IP (VIP) that “moves” between two Linux nodes: one MASTER and one BACKUP. We’ll use unicast VRRP (works even when multicast is restricted) and add optional health checks, fast ARP convergence, and clean failover testing.

What you’ll build

Two Linux servers sharing a single VIP.
Server A is MASTER (higher priority), Server B is BACKUP.
If the MASTER fails, the VIP moves to the BACKUP automatically.
Optional: service‑aware failover (priority drops if your app is down), plus small hooks to start/stop services when a node becomes MASTER/BACKUP.

Reference topology (adjust to your network)

Node A (MASTER preferred): 10.0.0.10 (interface: eth0)
Node B (BACKUP): 10.0.0.11 (interface: eth0)
VIP (IPv4): 10.0.0.100/24
VRID: 51 (1–255; must be the same on both nodes)

You can run IPv6 too. For IPv6 addresses, switch to vrrp_version 3 and use an IPv6 VIP (sample below).

Prerequisites

Root or sudo access on both nodes.
Internet access or install packages following this documentation.
Matching network segment for the VIP and both nodes.
Firewall allows protocol 112 (VRRP) between nodes.

1) Install Keepalived

RHEL/Rocky/Oracle Linux

sudo dnf install -y keepalived || sudo yum install -y keepalived

Debian/Ubuntu

sudo apt update && sudo apt install -y keepalived

2) Recommended network/sysctl settings

Enable binding to the VIP even when it’s not yet on the local node (useful if your app binds to the VIP):

echo "net.ipv4.ip_nonlocal_bind = 1" | sudotee /etc/sysctl.d/99-keepalived.conf
sudo sysctl --system

Firewall rules (allow VRRP protocol 112)

firewalld

sudo firewall-cmd --permanent --add-rich-rule='rule protocol value="vrrp" accept'
sudo firewall-cmd --reload

nftables (example)

sudo nft add rule inet filter input ip protocol vrrp accept
# persist ruleset
sudo nft list ruleset | sudotee /etc/nftables.conf

3) Keepalived configuration files

Edit /etc/keepalived/keepalived.conf on both nodes as shown.

Node A (MASTER preferred) — `/etc/keepalived/keepalived.conf`

vrrp_instance VI_1 {
  state MASTER
  interface eth0
  vrrp_version 2
  virtual_router_id 51
  priority 150
  advert_int 1
  # Unicast VRRP to avoid multicast requirements

  unicast_src_ip 10.0.0.10
  unicast_peer {
    10.0.0.11
  }

  authentication {
    auth_type PASS
    auth_pass SuperSecreto123
  }

  virtual_ipaddress {
    10.0.0.100/24 dev eth0 label eth0:1
  }

  # Faster neighbor convergence after failover
  garp_master_delay 1
  garp_master_repeat 5
  # Optional: avoid automatic failback to MASTER when it returns
  # nopreempt
  # Optional service health check (example: nginx)
  # vrrp_script chk_app {
  # script "pidof nginx >/dev/null 2>&1"
  # interval 2
  # weight -30
  # }
  # track_script {
  # chk_app
  # }
  # Optional hooks for service control on state changes
  # notify_master "/usr/local/bin/keepalived_notify master"
  # notify_backup "/usr/local/bin/keepalived_notify backup"
  # notify_fault "/usr/local/bin/keepalived_notify fault"
}

Node B (BACKUP) — `/etc/keepalived/keepalived.conf`

vrrp_instance VI_1 {
  state BACKUP
  interface eth0
  vrrp_version 2
  virtual_router_id 51
  priority 100
  advert_int 1

  unicast_src_ip 10.0.0.11
  unicast_peer {
    10.0.0.10
  }

  authentication {
    auth_type PASS
    auth_pass SuperSecreto123
  }

  virtual_ipaddress {
    10.0.0.100/24 dev eth0 label eth0:1
  }

  garp_master_delay 1
  garp_master_repeat 5

  # nopreempt # also here if you want to avoid failback
  # vrrp_script chk_app {
  # script "pidof nginx >/dev/null 2>&1"
  # interval 2
  # weight -30
  # }
  # track_script {
  # chk_app
  # }
}

Notes
virtual_router_id, advert_int, authentication and virtual_ipaddress must match across nodes.
MASTER’s priority must be higher than BACKUP’s. Default tie‑breaker is the higher primary IP.
Add more VIPs by listing additional addresses in virtual_ipaddress { … } (one per line).

4) Enable and start the service

Run on both nodes:

sudo systemctl enable --now keepalived
sudo systemctl status keepalived --no-pager
# live logs
journalctl -u keepalived -f

5) Validate and test failover

Confirm the VIP lives on the MASTER:

ip a show dev eth0 | grep 10.0.0.100

From a third host, ping the VIP:

ping 10.0.0.100

Force failover by stopping Keepalived on the MASTER:

sudo systemctl stop keepalived

Now check the BACKUP:

ip a show dev eth0 | grep 10.0.0.100

Start MASTER again (if nopreempt is not set, the VIP will return to MASTER):

sudo systemctl start keepalived

Optional: service control hooks (notify script)

Create a small script to start/stop your app when the node gains/loses the VIP.

/usr/local/bin/keepalived_notify:

#!/usr/bin/env bash
set-euo pipefail

STATE=${1:-}

case "$STATE" in
  master)
    systemctl start haproxy || true
    ;;

  backup|fault)
    systemctl stop haproxy || true
    ;;
  *);;
esac

sudo chmod +x /usr/local/bin/keepalived_notify

Then uncomment the notify_* lines in your keepalived.conf.

Troubleshooting & hardening

VIP doesn’t move / clients still hit old node: Increase gratuitous ARP: garp_master_repeat 5 (already in the sample). You can also manually nudge neighbors: arping -U -I eth0 10.0.0.100 -c 3 after a switchover.
Firewall drops VRRP: Ensure protocol 112 is allowed between nodes (see rules above). If using routers/L3 firewalls between nodes, allow it there too.
Service is up but traffic fails: If your app binds strictly to the VIP, make sure net.ipv4.ip_nonlocal_bind=1 and restart the app after VIP acquisition via notify_master.
Avoid flapping: Use health checks (vrrp_script) with sensible intervals, and consider nopreempt to keep the VIP on the current healthy node until you plan a controlled failback.
Multiple VLANs: Use a distinct virtual_router_id per broadcast domain to avoid VRID collisions.
Security: Use auth_type PASS only on trusted networks. For stronger integrity, consider VRRPv3 on IPv6 (different auth model) and/or host‑level controls.
