Install AWX on Kubernetes Rocky Linux 9: The Ultimate Step-by-Step Guide

Byluissb94

Running Ansible at scale is far smoother with AWX, the open-source upstream of Red Hat’s Ansible Automation Platform. In this guide, you’ll install AWX on Kubernetes Rocky Linux 9 using the AWX Operator for a clean, declarative setup. By the end, you’ll have a secure, reproducible deployment you can upgrade in place.

Why Install AWX on Kubernetes Rocky Linux 9

If you already run Kubernetes on Rocky Linux, consolidating automation there is natural. We’ll install AWX on Kubernetes Rocky Linux 9 so you get containerized orchestration, persistent storage, and easy upgrades managed by the AWX Operator.

Prerequisites

  • Rocky Linux 9 host(s) with a running Kubernetes cluster (e.g., v1.29).
  • kubectl (kustomize is built into kubectl).
  • A default StorageClass (for Postgres and project PVCs).
  • Optional but recommended: an Ingress Controller (e.g., NGINX Ingress) and DNS pointing to your Load Balancer/Ingress.
  • (If your environment uses a proxy) HTTP/HTTPS proxy variables ready.

Quick Architecture Overview

  • AWX Operator (runs in a namespace, reconciles CRDs and manages AWX lifecycles).
  • AWX control plane pods: web, task, redis, plus a managed PostgreSQL (unless you bring an external one).
  • PVCs for database and /var/lib/projects (optional but recommended).

Install the AWX Operator (kustomize)

Create a working directory and the namespace:

kubectl create namespace awx
mkdir -p ~/awx-operator-deploy && cd ~/awx-operator-deploy

Create kustomization.yaml — this is the correct, working version:

apiVersion: kustomize.config.k8s.io/v1beta1
kind: Kustomization

namespace: awx

resources:
  - github.com/ansible/awx-operator/config/default?ref=<TAG>
  - awx.yaml

images:
  - name: quay.io/ansible/awx-operator
    newTag: <TAG>

Note: Change <TAG> to match actual version.

Deploy an AWX instance

Create your AWX manifest awx.yaml. Pick one of the following options.

Option A — NodePort (quick for labs)

apiVersion: awx.ansible.com/v1beta1
kind: AWX
metadata:
  name: awx
spec:
  service_type: NodePort
  nodeport_port: 30080
  projects_persistence: true
  projects_storage_size: 20Gi

Apply:

kubectl apply -k .
kubectl -n awx get pods -w

Access via: http://<any-node-ip>:30080/

Option B — Ingress + TLS (recommended)

Create secrets (admin and secret key). If you’re not using cert-manager, create a TLS secret too.

# Admin password (optional; otherwise operator generates one)
kubectl -n awx create secret generic awx-admin-password \
  --from-literal=password='<a-very-strong-password>'

# Symmetric secret key for DB encryption (persist between upgrades)
kubectl -n awx create secret generic awx-secret-key \
  --from-literal=secret_key="$(openssl rand -hex 32)"

# If you do NOT use cert-manager, bring your own TLS certs:
# kubectl -n awx create secret tls awx-tls --key privkey.pem --cert fullchain.pem

Now awx.yaml:

apiVersion: awx.ansible.com/v1beta1
kind: AWX
metadata:
  name: awx
spec:
  service_type: ClusterIP
  ingress_type: ingress
  ingress_class_name: nginx
  ingress_hosts:
    - hostname: awx.example.com
      # tls_secret: awx-tls   # uncomment if you're NOT using cert-manager
  admin_user: admin
  admin_password_secret: awx-admin-password
  secret_key_secret: awx-secret-key

  # Persist project data (recommended)
  projects_persistence: true
  projects_storage_size: 20Gi
  # projects_storage_class: <your-sc>  # omit to use cluster default

Apply:

kubectl apply -k .
kubectl -n awx get pods,svc,ingress

Access via: https://awx.example.com/

First Login (admin credentials)

If you didn’t set awx-admin-password, retrieve the auto-generated one:

kubectl -n awx get secret awx-admin-password -o jsonpath="{.data.password}" | base64 -d; echo
  • Username: admin
  • Password: (the value from the secret above or the one you set)

Upgrades & backups

  • Upgrade: bump the AWX Operator tag in kustomization.yaml (it maps to a compatible AWX version), then kubectl apply -k ..
  • Backups: the operator ships AWXBackup/AWXRestore CRDs. Before major changes (e.g., Postgres jumps), take an AWXBackup.

Troubleshooting cheatsheet

  • Watch rollout: kubectl -n awx get awx awx -o yaml | sed -n '/status:/,$p' kubectl -n awx get events --sort-by=.lastTimestamp | tail -n 50 kubectl -n awx get pods -w
  • PVC stuck in Pending: kubectl -n awx get pvc kubectl get storageclass kubectl annotate storageclass <your-sc> storageclass.kubernetes.io/is-default-class="true" --overwrite
  • ImagePullBackOff: check registry connectivity and, if needed, proxy settings above.
  • Ingress 404: confirm ingress_class_name, DNS, and that your Ingress Controller is running.
